BWA536 Aluminium IP65 LED PAR 18x 12W 4-in-1

150.790

18x 12W 4-in-1 LEDs
RGBW colour mixing
25x different colour presets
Colour temperature 2700, 3200, 4300, 5600, 6500, 8000K
9x pre-programmed shows and adjustable speed
Electronic dimming: 0 – 100%
3, 4, 5 or 10 DMX channels
Strobe effect
Selectable colour fade and flash
DMX and Stand-alone mode
Master/Slave function
DMX in/output via 3-pin XLR
Control panel with LED display (touch button)
Display lock via password
Aluminium housing
Waterproof IP65 for outdoor use
Waterproof connectors, Powerconnector TR (in-out)
IR remote control

Specifications

Specifications
Description
Videos
Download & links

Product colour	Black
Light source	4-in-1 LED
Colours	Red, Green, Blue, White
LED power (single LED)	12W
Quantity of LEDs	18
Beam angle	22
Field angle	38
Illuminance	12.000 lx @ 1m
Flash rate per second	1 - 20Hz
DMX channels	3, 4, 5, 10
DMX connection	3-pin XLR
Modes	Automatic programs, DMX, Master/Slave
IP rating	IP65
Power plug	P-Con TR1
Power consumption	1.1 - 0.6A
Power supply	100-240VAC 50/60Hz
Dimensions (L x W x H)	310 x 300 x 155mm
Weight (kg)	5.2000
Included accessories	Remote control (wireless), Mounting bracket, Power cable

The BWA series is a series of robust aluminium PARs specifically designed for outside usage. By using the latest LED technology and advanced lenses the BWA series is able to create beautiful wash effects. These fixtures are suitable for a wide range of applications from uplighting a large venue or building to lighting up a stage for live performances. The BWA series also sports a convection cooled cast aluminium housing with watertight internal gaskets and weatherproof power and DMX cable in/out connections. All models come with an infrared remote control.
